IntoPrint

RP8525

The Power To Do More In Less Time. A unique digital press solution for short run label production. The RP8525 is a digital label press solution printing at speeds up to 25 feet/min for short run label production on a variety of die-cut, kiss-cut or roll substrates. Designed for in-house production of labels, users will be capable of printing 2000 labels in less than 20 minutes and have the finished roll ready for immediate application.
Brochure

The Intoprint RP8525 is a fast, affordable, narrow web digital label printer. The roll-to-roll RP8525 features an LED toner print engine that is capable of printing up to 25 feet per minute. The results are beautiful and professional labels with a wide color gamut, fantastic definition, and deep, rich blacks. You can create a wide range of applications due to extensive media choices, including: papers, polyesters and vinyls. The RP8525 can print on substrates 6.5 to 8.5 inches wide on rolls with a maximum outside diameter of 12 inches. The top, bottom and gap sensors allow printing on roll or pre-die cut label substrates.

A Wasatch Software RIP adds flexibility to digital label workflow including, rendering very small text and line work, cost estimating, custom color profiling and spot color replacement. SoftRIP is the RIP that color experts choose most. SoftRIP produces perfectly smooth gradients without a hint of stair stepping. With the industry’s first 16-bit color pipeline, and our Precision Stochastic Screens (PSS) halftoning, Wasatch is the RIP leader in producing superior image quality. An optional variable data module allows you to change images, texts or barcodes on every label.

The RP8525 when combined with Intoprints offline finisher provides a complete solution that enables you to print and finish labels on demand, with each label having unique content and shape. All the tools you need to compete in today’s short run, quick turn around environment. Most important, due to it’s low acquisition and operational costs, the Intoprint RP8525 Printer’s cost per label is amongst the lowest in the industry. All this lends itself to a superior return on your investment. With Wasatch, adding variable data customization to your inkjet workflow is easy. Customize variable data fields with fonts, barcodes, QR codes, and Data Matrix codes, with a variety of sizing, color, and effect features. Instantly create repeating or sequential values with SoftRIP’s Auto-Data feature or import data from a comma-delimited text file.

  • Print Technology LED Toner
  • Speed Up to 25 feet/min
  • Resolution Up to 600 x 1200 DPI
  • Interfaces Ethernet 10/100/1000 Base-T or USB 2.0
  • Media Width 6.5-8.5 in.
  • Print Width Up to 8.24 in.
  • Input Roll Diameter Up to 12 in.
  • Media Core Dimensions 3”
  • Dimensions (WxDxH) 40” X 24“ X 52”
  • Weight 252.8 lbs
  • Toner Supply Life CMY - 11,500 pages @ 5% coverage K - 11,000 pages @ 5 % coverage
  • Drum Supply Life CMYK - 30,000 pages @ 5 %
  • Power Requirement 900 watts 100-132 VAC / 47-63 Hz or 180-240 VAC / 47-63 Hz
  • Warranty Limited 1 year
  • Wastach SoftRIP Stochastic Screening
  • Variable Data Optional
  • Software Compatibility with Windows 7, 8 and 10 operating systems
